Portable buildings and modules for Saint-Gobain in France | Prefabri Africa

/in , /by

Prefabri Africa has carried out a new modular construction project in France. On this occasion, we have designed and manufactured two portable buildings and two prefabricated modules for a Saint-Gobain Group company that are located in the Paris area.

This is a project with special characteristics, in which the design of the portable buildings has been adapted to the customer’s needs. Taking into account the use that the client will give to the constructions, the materials and the level of insulation have been adapted to the applicable thermal regulation (RT2012).

The portable buildings are composed of two prefabricated modules measuring 6.00×2.40m each. Its internal height has been increased to 2,700mm. In addition, we will also provide a ramp to access the buildings as well as an entrance canopy. In compliance with French regulations on retail spaces, the ramp and access door have been designed in accordance with the requirements for people with reduced mobility.

Technical Features: Portable buildings and modules for Saint-Gobain

 portable buildings

Floor structure

The main floor structure of the portable buildings is composed by galvanized sheet profiles of 2.00 mm thickness shaped in cold. Transversally, Omega straps are placed, providing more stability to the floor for facing vibrations and charges. The straps support an 18 mm thick phenolic plywood board covered with grey vinyl PVC floor covering Sintasol Traviata 6026 (grey).

For insulation, we have placed sandwich polyurethane panels of 100mm thickness between the straps and the plywood.

The entire floor supports loads of 250 kg/m2 using, uniformly distributed.

Roof structure

The roof structure frame in the modular building is formed by 2 vertical and 2 horizontal galvanized profiles of 2.00 mm thickness shaped in cold. OMEGA galvanized steel straps are placed transversally. These Omega steel straps support a trapezoidal galvanized metal sheet of 5 notches with the thickness of 0.6mm attached to the profiles by means of self-threading screws with washers.

Columns

The columns are formed by asymmetric galvanized steel profiles shaped in cold of 2.00mm thickness. The columns are screwed to the floor structure and roof structure using special screws. There is a round PVC pipe with the diameter of 75mm serving as a gutter hidden in the interior of the column. The column is finished on its interior with a lacquered sheet that fastens the electrical mechanisms, plugs, switches and electric protection panel.

Lateral enclosure

The side walls are formed by PUR sandwich panels 80mm thick. Each panel consists of 2 lacquered galvanized steel sheets with a thermal and acoustic insulation polyurethane layer in the middle. The polyurethane is injected with a density of 40 kg/m3.

The thermal transmission coefficient is K=0,44 Kcal/m2 h ºC. In terms of fire resistance, this kind of panel is classified as M2 material.

False ceiling

The false ceiling is formed by galvanized and pre-lacquered metallic blades in white silicone polyester (0.5mm thickness). Between the false ceiling and the roof plate, we placed a double 80+80mm insulation fiberglass blade with vapour barriers.

Carpentry

In order to guarantee compliance with thermal insulation requirements and avoid heat loss, for all the windows and glazed panels we used double glass with an air chamber 4+4/16GAS/4+4, assuring thermal break.

Electrical installation

The electrical installation system is complete except for the electrical line up to the location of the module. All the electrical system and installations are adapted to the safety requirements.

Electrical supply is connected to the electrical box with an independent protection via magneto-thermal switches and switches necessary for lighting, emergency devices (in case of having ones), air conditioning and other uses. The box is protected against the direct and indirect contacts, over current or short circuit.

Transport and assembly

We transported the prefabricated modules already assembled in order to facilitate on site installation. Due to the height of the modules, the use of special transport was necessary. Access ramps and entrance canopies were supplied disassembled.

PREFABRICATED WORK CAMPS | PREFABRI AFRICA

/in , /by

Prefabri Africa is specialized in the design, manufacture and assembly of prefabricated work camps. We take part in construction, mining, oil & gas sectors. We also manufacture refugee camps.

We provide a complete service, which includes design, fabrication, transport and assembly of constructions at the place indicated by our clients.

We have available two modular construction systems based on client’s needs:

  • MODULAR CONSTRUCTION SYSTEM (CM)
  • FIXED MODULAR CONSTRUCTION SYSTEM (CMF)

Moreover, we have at our disposal high-standard products, made thanks to an European technology designed to withstand climatic conditions, cold, extreme heat and humidity.

PREFABRICATED WORK CAMPS: MODULAR CONSTRUCTION SYSTEM

Our modular construction system is based on fabrication and assembly of the free-standing prefabricated modules realized with a galvanized steel structure and insulating sandwich panels enclosing walls.

Those prefabricated modules can be used for independent spaces or for modular units via an assembly of different modules horizontally or vertically.

With this system there is no need to modify the foundations because the module is not fixed in the ground. Modules can be moved easily, that is why it is a perfect option for temporary or permanents camps.

Moreover, the CM system allows us to transport the modules in KIT (or Flat-Pack), which facilitates the on-site assembly, that can be done by untrained staff.

In addition to standard models, we manufacture made-to-measure modules with different dimensions, technical characteristics, interior layouts and equipment.

FIXED MODULAR CONSTRUCTION SYSTEM

We recommend choosing this system for projects such as permanent workspaces, which require a combination of specific spaces:  cafeterias, bedrooms, workshops and warehouses.

This system is based on metallic manufactured structures that are fixed to the slab previously made. The lateral enclosure is made with sandwich panels composed of steel sheet and polyurethane foam or Rockwool. The displacement to a new place requires the whole disassembly of the modules that is why this system is rather recommended for permanent camps.

Compared to  CM system, it provides a lot of advantages such as the versatility of the assembly, reduced costs, reduced transportation costs by delivering the materials disassembled but also  the possibility to get more opened-spaces, without pillars.



Security Portable Cabin for a photovoltaic power plant l Prefabri Africa

/in , /by

Prefabri Africa has carried out a new modular construction project applied to industrial solutions in Valencia. On this occasion, we installed two security portable cabins that will be used by the engineers of this photovoltaic plant to monitor the operation and production of the solar panels of the plant.

Our prefabricated solutions are ideal for this type of usages, given the advantages they offer with regard to traditional construction: logistical ease, quick installation of the structures, the minimal need of civil works and the modulation of spaces.

In this case, each of the security portable cabins is composed of a set of modules formed by two prefabricated diaphanous modules assembled. We used modules of 6,00×2,35m so the surface of each portable cabin goes up to 30m2. The security cabins are divided into two distinct areas: a working area for the engineers and a storage area for materials and control devices, which are connected by a sliding door. In the storage area, the floor structure has been reinforced to support a maximum load of 1200kg/m2 uniformly distributed. The modules were installed directly by Europa Prefabri with two technicians on site.

Technical specifications of the project: Security Portable Cabins for a photovoltaic power plant

Floor structure

The floor structure frame is formed by 2 vertical and 2 horizontal galvanized sheet profiles mm shaped in cold. There are OMEGA galvanized steel straps placed transversally achieving major stability supporting vibrations and heavy load. These straps support a water resistant phenolic plywood of 18mm thickness covered with grey PVC vinyl covering.

The floor structure described supports up to 250 kg/m2 uniformly distributed. We reinforced the floor structure in the storage area to a maximum load of 1200kg/m2.

Roof structure

The roof structure is formed by 2 vertical and 2 horizontal galvanized profiles shaped in cold. There are OMEGA galvanized steel straps placed transversally. These Omega steel straps support a trapezoidal galvanized metal sheet of 0.6mm thickness.

Columns

The columns are formed by asymmetric galvanized steel profiles shaped in cold of 2.00mm thickness. The columns are screwed to the floor structure and roof structure using special screws. There is a round PVC pipe with the diameter of 75mm serving as a gutter hidden in the interior of the column. The column is finished on its interior with a lacquered sheet that fastens the electrical mechanisms, plugs, switches and electric protection panel.

Side walls

The lateral closure is composed of sandwich panels, of 40 mm thickness. These sandwich panels are made of a two sided lacquered sheet on a galvanized base and count with intermediate thermal and acoustic isolation. In terms of fire resistance, this kind of panel has been classified as M2 material, which means it is highly fire resistant. It has been proven to be highly resistant to water, remaining unalterable over time.

False ceiling

The false ceiling is formed by galvanized and pre-lacquered metallic blades in white silicone polyester (0.5mm thickness). Between the false ceiling and the roof plate is placed an 80mm insulation fiberglass blade with vapour barriers.

The internal free height of these modules is 2.475 mm.

External and internal carpentry

The external and internal carpentry of the security portable cabins is manufactured in PVC or aluminium profiles lacquered in white.

The named carpentry consists of:

  • Exterior door 815x2060mm with a handle and a lock.
  • Interior sliding door 1200x2300mm with a handle.
  • White PVC 2 wing sliding window 815x1045mm.
  • White WC window 1 wing 815x500mm.
  • White PVC 2 wing sliding window

Electrical installation

The electrical installation system is complete except for the electrical line up to the location of the module. All the electrical system and installations are adapted to the safety requirements.

Electrical supply is connected to the electrical box with an independent protection via magneto-thermal switches and switches necessary for lighting, emergency devices (in case of having ones), air conditioning and other uses. The box is protected against the direct and indirect contacts, over current or short circuit:

  • Waterproof lights with diffuser 2x36W
  • Oval Outdoor Wall Light 60w
  • Plug entries 16A+TT (when placed in the bathrooms these are waterproof)
  • Surface switches of 10A+TT

In addition, we carried out the complete installation of voice and data supplies for the security portable cabins.

TRADITIONAL OF PREFAB HOMES?

/in , , /by

Until now, when we asked ourselves whether we wanted traditional or prefab homes, the answer was always quick: we preferred traditional ones.

Traditional construction assures security, as the house is built with bricks and concrete; and offers variety of designs and durability over time. However, more and more families are discovering the advantages of prefabricated construction.

Prefab homes arise as a result of the evolution that architecture and engineering have undergone in recent years. This evolution resulted in the application of the highest technology to finishes, designs and construction materials, thus allowing the appearance of a wide variety of prefab homes: steel, wood, concrete… all of them with two characteristics in common: reduced costs and shorter construction time.

Prefab homes have many advantages. Among them we can highlight: construction time, which is reduced by half compared to traditional construction; use of high quality materials, that show high resistance to climate changes and meteorological phenomena; portability, being recoverable by more than 90%; safety, provided by the appropriate assembly technique; variety of designs, with more than a thousand finishes; minimum maintenance needed and, of course, reduced costs.

In Silicon Valley itself, where access to housing is difficult even for engineers from large companies like Amazon and Google, these companies have ordered 300 prefab homes for their employees, saving up to $700 a month.

Former employees of huge companies like Aaron Holm, who worked in product management for Amazon, or Michael Marks, one of Tesla’s first investors, have been quick to create startups dedicated to the manufacture and assembly of prefab homes. The business incubator Y Combinator, cradle of the successful Airbnb, Dropbox or Reddit, has also decided to invest in this future-oriented construction and has gone one step further: it has created a startup, Acre Desingns, which creates prefabricated and energy-efficient homes.

edificios prefabricados prefabri africa

Manufacture and assembly of site office at Reims (North of France)| Prefabri Africa

/in , , /by

Prefabri Africa has carried out a new modular construction project in France. Last October we have finished the manufacture and assembly of three different site offices at Reims (North of France) for construction project purposes.

Technical features: Site offices at Reims

  • First tranch site offices: composed of 3 portable cabins of 6 x 2,40 m, one of them with a bathroom.
  • Second tranch site offices: composed of 5 portable cabins of 6 x 2,40 m, one of them with a restroom.
  • Third tranch site offices: composed of 15 portable cabins of 6 x 2,40 m, in two heights, with outside stairs. In this ensemble, there are 3 full restrooms.

For transport and logistics, we have manufactured 5 portable bathrooms for the site office completely finished and the other portable cabins have been manufactured and transported on KITS, for its assembly at the construction works.

As you will see in the pictures we attach, the structure is painted in the customer’s corporate colour.

The manufacture of the different site offices has been made with double panel in most of the modules to allow its individual use in the future or with different configurations. As permanent or temporal works infrastructure, portable cabins construction camps are the best option for easy assembly solutions.

The insulation of walls and windows can be adapted in thickness of material to adapt to any climate conditions or fire/sound proof applications in order to always offer the best solution and features to each project.

The spaces created with the different portable cabins and prefabricated modules can be easily adapted to the project needs: offices, dining halls, dressing rooms, bathrooms and sanitary facilities.


ADVANTAGES OF MODULAR CONSTRUCTION


Sustainability and recycling

Prefabri Africa is environmentally engaged, that is why our products are recyclable and can be dismantled. Industrialized construction allows a more efficient use of resources, by reducing toxic emissions and generating less waste.

Quality

construccion modular solucion constructiva para empresas europa prefabri

Industrialized construction in factory allows applying different quality controls in the production process, benefiting labour risk prevention by working on safer environments. On the other hand, it allows having a total control on the product manufacturing.

Customisation

Each customer is unique and has specific needs. The versatility of modular construction allows us to adapt our products to each customer, customizing the dimensions, distribution, materials and finishing of the constructions.

Insulation

We use innovative light materials that can have better levels of thermal and acoustic isolation and energy efficiency compared to traditional constructions.

A completely finished steel structure that consists of a floor-structure, a ceiling structure and pillars, each of them with its independent structural elements, compose prefabricated modules.

Dissembling and transportation

All modules can be easily transported, completely assembled in trucks, but also disassembled or in KIT (Flat-Pack system), which allows us to transport several modules in one truck or sea container, reducing transportation costs.

The design of our modules enables to assemble and disassemble them easily, even by personnel without any previous experience, thanks to the instructions and videos we provide.

cabinas de vigilancia prefabri africa

Prefabricated Security Guard Cabin at Ivory Coast | Prefabri Africa

/in /by

We carried out a new modular construction project in Ivory Cost. On this occasion we provided a prefabricated security guard cabin for a client at Abidjan.

Technical features: Prefabricated Security Guard Cabin Ivory Coast

Floor structure

The floor structure frame of the prefabricated security guard cabin is formed by galvanized sheet profiles shaped in cold. There are OMEGA galvanized steel straps placed transversally achieving major stability supporting vibrations and heavy load. This floor structure supports up to 250 kg/m2 uniformly distributed.

  • 18mm thickness special anti-humidity phenolic plyboard floor
  • Covering: sintasol Traviata 6026

Roof structure

The roof structure frame for this porta cabin is formed by longitudinal galvanized profiles and transversal straps conformed in cold. There are OMEGA galvanized steel straps placed transversally. These omegas support a trapezoidal sheet of 0.6mm thickness, screwed to the profiles through self-tapping screws with waterproof washers.

Columns

The columns are formed by galvanized sheet profiles shaped in cold. These columns are screwed to the floor and the roof of the porta cabin with special screws. There is a round PVC pipe with the diameter of 75mm serving as a gutter hidden in the interior of the column. A lacquered metal sheet in the interior of the module that fastens the electrical mechanisms, plugs, switches and electric protection panel covers the column.

Side walls

The lateral closure is composed of PUR 40mm thick insulating sandwich panels. Each panel consists of two lacquered galvanized steel sheets with a thermal and acoustic insulation layer in the middle formed by injected polyurethane self-extinguishing resins.

The panel is very resistant against humidity, staying unalterable over the years.

False ceiling

The false ceiling of the porta cabin is formed by galvanized and pre-lacquered metallic blades in white silicone polyester (0.5mm thickness). Fiberglass insulating material of 80mm thickness and vapour barrier is placed between the roof structure and the false ceiling.

The internal free height of this module is 2.275mm.

External carpentry

The external carpentry of the guard porta cabin is fabricated in white aluminium profiles.

The carpentry of this cabin is composed of:

  • Exterior door 975x2060mm with a handle and a lock
  • Glazed panel in white aluminium. Glass 3+3.
  • Sliding window 1800x1200mm.

Electrical installation

The electrical installation of the guard porta cabin is complete except for the electrical line up to the location of the module.

All the electrical system and installations are adapted to the safety requirements of low voltage. Electrical supply is connected to the electrical box with an independent protection via magneto-thermal switches and switches necessary for lighting, emergency devices (if necessary), air conditioning and other uses. The box is protected against the direct and indirect contacts, overcurrent or short circuit.

  • Waterproof lights with diffuser 2x36W
  • Plug entries 16A+TT
  • Surface switches of 10A+TT

In the standard prefabricated modules the electrical wiring is concealed behind the false ceiling and the tops of the columns, so the whole electrical installation is completely hidden.

Finishing

  • The whole structure of the guard cabin was painted in grey.



Parking shades for the T1 Parking at Madrid Barajas Airport

/in , /by

Prefabri Africa is carring out the installation of 1.200 parking shades made with our metal canopies with a galvanized steel cover. Additionally we are conducting a walking corridor with a polycarbonate cover. There have been delivered already the first 600 spots in just 20 days. Following we show you some pictures of the plant, we hope you like it.

The installation of parking canopies at Madrid Barajas Airport was carried out in several phases in order minimise disruption for passengers. We have installed also tensile canopues and carports for the VIP parking.



Besides the metallic parking canopies, Prefabri Africa has a wide range of parking shades.

Our range of parking shades:

Tensile Canopies

  • Innovative textile architecture for multiple uses with modern designs:
  • The guarantee a perfect aesthetic harmony with security and materials quality.
  • They are modular structures that can adapt to the spaces geometrics.
  • Its versatility goes further the usability as parking canopies for cars, as they can also be used in terraces and gardens for shadow areas.

Europa Model

  • With a box-type girder made with sheets of folded steel.
  • It is an aesthetic parking canopy, low cost available in simple or double version.
  • Galvanised or pre-lacquered cover on the colour chosen by the customer.
  • Maximum safety and quality of the materials used.

IPE Model

  • Detachable parking canopy made of hot galvanised steel girders model IPE.
  • Maximum strength of the structure capable of withstanding overloading of wind and snow.
  • There are different versions depending on the type of girders used.
  • Galvanised or pre-lacquered roof in the colour the customer demands.
  • Hot-galvanised structures upon request.

Ibiza Model

  • Special design with metal trusses diamond-shaped roof.
  • Hot galvanized structure upon request.
  • Different simple or double versions.
  • Galvanized or pre-lacquered roof, colour upon customer’s request.

Panel cover

  • We substitute the cover galvanised panel sheet by an isolating sandwich panel to offer a better thermal and acoustic isolation.
  • Available solution in all the parking canopy models.
  • Different options for the panel: polyurethane, polystyrene and rockwool.

Solar carport structures

  • As a company specialized in manufacturing of parking canopies, we have developed several models of solar carport structures in order to bear the load of photovoltaic panels on the roof.
  • We manufacture our models as well as the customers’ design. We also develop turnkey solutions that include the supply and assembly of the photovoltaic facilities.
  • We also advice our customers in order to find the energy and structural solution that better adapts to the customer’s project.
  • It is also possible to add charging stations for electric cars (fotolineras).

Ola Model

  • Special design of the cantilever carport with a curved shape and folded-steel frames.
  • Galvanized or pre-lacquered roof with colour chosen by the customer.
  • Hot galvanized structures upon customer’s request.
  • Possibility of adapting the model depending on the customers’ needs.

Celosía Model

  • Parking canopy made by metallic lattice with welded profiles.
  • Different versions, simple or double.
  • Galvanized and pre-lacquered roof, colour upon customer’s request.
  • Hot galvanized structures upon request.
  • Maximum security and material quality.
  • Possibility of adapting the models depending on the customers’ needs.

Cable-stayed model

  • Special parking canopy with an original design made with hot-rolled steel beams with metallic straps.
  • Possibility of a pedestrian hallway with polycarbonate roof in double spaces.
  • Galvanized or pre-lacquered roof, colour chosen by the customer.
  • Hot galvanized structures upon customers’ request.
  • Maximum security and materials quality.
  • Possibility of adapting the model depending on customers’ needs.





Prefabricated modular building for Airbus | Prefabri Africa

/in , , /by

Prefabricated dressing rooms for Airbus at Sevilla

We have just finished the assembling of the prefabricated modular building for the Airbus Group at Sevilla.

Airbus Group is the spearheading of aerospace and defence sector in Spain, as it is one of the most important industrial corporations on an international level in the aerospace sector and the first helicopter manufacturer in the world.

The company had its origins in Construcciones Aeronáuticas S.A. (CASA), a pioneer enterprise of Spanish Aviation, created by José Ortiz Echaqüe in 1923. In the year 2000, after the fusion of CASA with Aerospatiale-Matra and DaimlerChrysler Aerospace AG (DASA), they became the European Aeronautic Defense and Space Company (EADS). In 2014, after reorganizing, they called themselves Airbus Group.

They currently work in Spain and employ more than 11.000 workers.

Our project to them was assembling a prefabricated building for dressing rooms of 955 m2, covered in rockwool sandwich panel of 60 mm with AENOR certificate at Airbus’ factory at Sevilla, south area. The total dimensions of the building were 55,97 x 17,14 meters, assembling 63 modules of 6,62×2,35.

The whole building meets the requirements of the Technical Building Code (CTE), for structural features and thermal and acoustic isolation.

Inside the building we have installed bathroom facilities, electricity and air conditioning.

Applications for a prefabricated modular building:

  • Permanent and temporary prefab Offices
  • Prefabricated schools.
  • Dressing rooms and dining rooms.
  • Portable
  • Cabing guard modules.
  • Portacabins
  • Telecom shelters
  • Control cabins and rooms

Our most important projects in Spain for 2016 were:

  • Preferential carport parking at Málaga’s airport for AENA, with 90 parking spaces OLA model with a “small wave” roof, divided into two simple modules, the first of them with 59 spaces and the second with 31 spaces. They have also provided 3 special parking canopies to cover the barrier for entrance and exit of the parking, and also another special parking canopy to cover the parking paying machines.
  • Málaga Fair: 50 modules for different uses, at the Cortijo de Torres Fairground.
  • DECODE Festival: 50 modules for different uses, such as dressing rooms for artists, production offices, ticket offices, bathrooms…
  • Mutua Madrid Open (Master 1000): ticket office modules painted in the corporation colour for the sports event and office modules for some enterprises that took part in the tournament.
  • Viñarock: supply of all the prefabricated modular building types for offices, ticket offices, dressing rooms and other uses, being a total of 60 modules. Where there were innovative products such as a module for Caja Rural that will be used for ATMs.
  • Service for Fire Prevention: prefabricated modules for security transported to their final destination by using a helicopter.
  • Red Crane Group: office prefabricated modular building. The building is made of 7 modules of different dimensions attached to form the required conditions asked by the customer. The modules have been made with standard technical features and glass frontals with a security glass.
  • Barajas airport parking: we have replaced the old carports, dismantling more than 1.200 spaces, we have cleaned up the area and manufactured and assembled 1.300 new parking spaces custom-designed by our customers, under AENA’s supervision. The works were done in 4 phases, to avoid the closure of the parking facilities.
edificios prefabricados prefabri africa

INSTALLATION OF PREFABRICATED HOUSING

/in , /by

PREFABRI STEEL, a company that is part of the EUROPA PREFABRI Group, is specialised in the design and fabrication of all kind of prefabricated buildings. In this video you can observe the process of the installation of a social housing conducted with metal structures and a closing consisting of lightweight concrete panels.

BATIMAT 2015

/in , , /by

Dear friends,

We are glad to announce that we are exhibitors once more at the international fair BATIMAT 2015 that takes place this week in Paris. We would like to invite all our friends and clients to come to visit us and thank the ones who already came.

BATIMAT is the most important faire in the construction sector in France and one of the most important worldwide. Every year, thousands of exhibitors show their brand new products to an international public. http://www.batimat.com

During all the week, we will present our products directed to export and mostly our new innovative system of industrialized construction for housing, hospitals, shopping centres, industrial buildings…

We are waiting for you at: Hall 5A – Stand D16.



IMG-20151103-WA0006-Copy IMG-20151103-WA0005-Copy IMG-20151103-WA0003-Copy IMG-20151104-WA0016-Copy IMG-20160215-WA0007-Copy IMG-20160216-WA0000-Copy IMG-20151103-WA0002-Copy IMG-20151104-WA0014-Copy IMG-20151104-WA0013-Copy IMG-20151104-WA0011-Copy IMG-20151104-WA0009-Copy
